Product Details:
Place of Origin: china
Brand Name: Testeck
Certification: CE,ISO9001CRCC
Model Number: TY-S13
Payment & Shipping Terms:
Minimum Order Quantity: 200
Price: Negotiable
Packaging Details: Customized packing
Delivery Time: 10-15
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000 pieces each month
Contact Now
Detailed Product Description
Type: In Put Usage: Convenient Installation Input Type Liquid Level Transmitter
Grade: Probe IP68, Transmitter Housing IP65 Output Signal: 4-20mA
Response Time: ≤20ms Application: Water
Color: Bule Or White Communication: LoraWan
Working Temperature: -50~300℃ Input: RTD
Operation Temperature: -40~85℃
High Light:

IP68 Digital Temperature Transmitter

,

IP65 Digital Temperature Transmitter

,

Probe IP68 Thermocouple Temperature Sensors Liquid Level Transmitter

Housing IP65 Probe IP68 Digital Temperature Transmitter Liquid Level



Convenient Installation Input Type Liquid Level Transmitter



Introduction

temperature transmitter is a kind of two wire intelligent temperature transmitter with PC configuration. It receives signal from PT100 thermal resistance, then transform it to 4~20mA through linearization process, and it allows users to set up ranges. The LED display will provide a long-term and reliable use in industrial environment.



Specification

Range: -50ºC~300ºC
Output: 4~20mA
Display: 4 LED
Power Supply: +12~+36VDC
Pressure Port: G1/2 or customized
Accuracy: 0.5ºC
Working Environment: -40ºC~85ºC, humidity<85%RH



Product parameters

Specifications Parameters
GL-136FTWD Convenient Installation Input Type Liquid Level Transmitter
Measuring range -50-100 (can be customized arbitrarily within the measuring range)
Accuracy 0.5%F.S
Output signal 4—20mA
Load <500Ω
Operating temperature -50-300℃
Protection grade Probe IP68, transmitter housing IP65
Temperature drift on zero 0.03%FS/℃(≤100KPa)0.02%FS/℃(>100KPa)
Temperature drift on full scale 0.03%FS/℃(≤100KPa)0.02%FS/℃(>100KPa)
Operating Voltage 12-36VDC



 Application of Company Products

It is widely used for the temperature measurement in such industries as petroleum, chemical, metallurgy, environmental protection, food, water conservancy, urban water supply, oil fields and others.



4. Product Details



Good stability, high precision, high performance/price ratio, directly put into the measured medium, easy to install and use, solid structure, no moving parts, high reliability, long service life, 4-20mA output.



Housing IP65 Probe IP68 Digital Temperature Transmitter Liquid Level 0
