| Place of Origin: | China |
| Brand Name: | Testeck |
| Certification: | Iris，CRCC，EN |
| Model Number: | MTB-HSYPZ |
| Minimum Order Quantity: | 1000 |
|---|---|
| Price: | Discussion |
| Packaging Details: | Customized packing |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 pieces each month |
| Voltage Class: | 300V | Temperature Range: | -40℃～90℃ |
|---|---|---|---|
| The Bending Radius Is Less Than: | 6D（D Is The Outer Diameter Of The Cable） | Characteristic Impedance: | 120Ω±12Ω（0.5～2MHZ） |
| Attenuation: | <1.0dB/100m（1MHZ） <1.4dB/100m（2MHZ） | Transfer Impedance: | <20mΩ/m（20MHZ） |
| Working Capacitance: | ≤65PF/M（1.0MHZ） | Capacitance To Ground: | ≤1.5PF/M（1.0MHZ） |
| High Light: | 120Ohm Railway Cable,MVB Railway Cable,MVB railroad cable |
||
120 Ohm Railway Cable MVB WTB Bus Aluminum Foil Tinned Braiding
120 Ohm WTB Bus Aluminum Foil And Tinned Braiding
we supply data cable and bus(MVB and WTB) railroad cable high quality with UL TUV SGS certificated. we devoted ourselves to cable and wire manufacture many years,covering most of Europe and the Americas market. We are expecting become your long term partner in china.
data cable and bus(MVB and WTB)
Ⅰ. Product Introduction of the data cable and bus(MVB and WTB)
data cable and bus(MVB and WTB) is based on the fireproof performance requirements of the rail transit industry. Under the fire, the smoke is very small when the cable burns, and the smoke is not toxic, corrosive and extended. The cable has good EMC property. It is used for multifunctional data transmission in the train
Ⅱ. Product Parameter (Specification) of the data cable and bus(MVB and WTB)
| Model | Core x sectionmm² | Conductormm | Insulationmm | Cable outermm |
| MTB-HSYPZ | 2x0.5 | 0.9 | 2.2 | 7.9 |
| MTB-HSYPZ | 2x0.75 | 1.15 | 3.7 | 9.3 |
| Model | Core x section mm² | Conductor mm | Insulation mm | Cable outer mm |
| MVB-HSYPZ | 2x0.5 | 0.9 | 2.85 | 7.8 |
| MVB-HSYPZ | 4x0.5 | 0.9 | 2.5 | 8.3 |
Ⅲ. Product Feature And Application of the data cable and bus(MVB and WTB)
This kind of data cable is based on the fireproof performance requirements of the rail transit industry. Under the fire, the smoke is very small when the cable burns, and the smoke is not toxic, corrosive and extended. The cable has good EMC property. It is used for multifunctional data transmission in the train.
Ⅳ. Product Details of the data cable and bus(MVB and WTB)
control cable
① The conductor is made of multistrand tinned copper.
② Solid polyolefin is used for insulation.
③ Aluminum foil + tinned braiding are used for shielding.
④ Sheath is made of low-smoke, halogen-free and flame-retardant polyolefin (black).
