| Place of Origin: | shenzhen |
| Brand Name: | Testeck |
| Certification: | CE，ISO,CRCC |
| Model Number: | TY-S09 |
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customized packing |
| Delivery Time: | 15-30 |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 pieces each month |
| Type: | PT100 | Operating Temperature: | -50-110℃ |
|---|---|---|---|
| Apply For: | Adjustable Input Type Temperature Transmitter | Pipe Material: | Sus304 Stainless Steel |
| Grade: | Probe IP68, Transmitter Housing IP65 | Installation Method: | Flange, Thread, Etc. Can Be Selected (contact Customer Service For Details) |
| Accuracy Error: | ±0.1% | Output Signal: | 4-20mA.DC |
| Name: | 24V Dc Adjustable Input Type Temperature Transmitter | Usage: | Industrial |
| Power Supply: | 24VDC | ||
| High Light: | 24VDC Thermocouple Temperature Transmitter,PT100 Thermocouple Temperature Transmitter,24VDC Industrial Transmitter |
||
Adjustable 24VDC Thermocouple Temperature Transmitter Industrial Use
24V DC Adjustable Input Type Transmitter Digital Temperature Transmitter
Product parameters
| Specifications | Parameters |
| GL-136FTWD | 24v adjustable Input-type temperature transmitter |
| Measuring range | -50-100 (can be customized arbitrarily within the measuring range) |
| Accuracy | 0.5%F.S |
| Output signal | 4—20mA |
| Load | ＜500Ω |
| Operating temperature | -50-100℃ |
| Protection grade | Probe IP68, transmitter housing IP65 |
| Temperature drift on zero | 0.03%FS/℃(≤100KPa)0.02%FS/℃(＞100KPa) |
| Temperature drift on full scale | 0.03%FS/℃(≤100KPa)0.02%FS/℃(＞100KPa) |
| Operating Voltage | 12-36VDC |
Application of Company Products
It is widely used for the temperature measurement in such industries as petroleum, chemical, metallurgy, environmental protection, food, water conservancy, urban water supply, oil fields and others.
Product Details
Good stability, high precision, high performance/price ratio, directly put into the measured medium, easy to install and use, solid structure, no moving parts, high reliability, long service life, 4-20mA output.
