| Place of Origin: | China |
| Brand Name: | Testeck |
| Certification: | CE，ISO |
| Model Number: | TY-S |
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | agree |
| Packaging Details: | Customized packing |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 pieces each month |
| Type: | PT100 | Operating Temperature: | -50-100℃ |
|---|---|---|---|
| Ambient Temperature In Application: | Refer To Temperature Measurement Range And Tolerance | Pipe Material: | Default 304 Stainless Steel (please Contact Customer Service For Other Information) |
| Protection Grade: | Probe IP68, Transmitter Housing IP65 | Installation Method: | Flange, Thread, Etc. Can Be Selected (contact Customer Service For Details) |
| High Light: | IP65 Digital Temperature Transmitter,304 SS Digital Temperature Transmitter,PT100 Probe Temperature Transmitter |
||
IP65 Integrated Digital Temperature Transmitter 20mA PT100 Probe
Integrated Field Display Input Temperature Transmitter Module 4-20mA Output Sensor PT100 Probe
Characterized by integrated installation and compact size, GL-136FTWD input-type temperature transmitter is cost-effective, economical and practical, designed with output two-wire 4-20mA signal. It is widely used for temperature measurement in such industries as petroleum, chemical, metallurgy, environmental protection, food, water conservancy, urban water supply, oil field and others. Thanks to the excellent quality, the input-type temperature transmitter meets the needs of industrial automation and can function as pool temperature detection instrument for measurement automation in some industries.
Ⅰ.GL-136FTWD input-type temperature transmitter
Input-type temperature transmitter is used. The resistance generated by the thermal resistor passes through the bridge of temperature transmitter to generate an unbalanced signal which, after being amplified and converted into a 4-20mA DC signal, is delivered to the working instrument, and the working instrument displays the corresponding temperature value.
Ⅱ. Product parameters
| Specifications | Parameters |
| GL-136FTWD | Input-type temperature transmitter |
| Measuring range | -50-100 (can be customized arbitrarily within the measuring range) |
| Accuracy | 0.5%F.S |
| Output signal | 4-20mA |
| Load | ＜500Ω |
| Operating temperature | -50-100℃ |
| Protection grade | Probe IP68, transmitter housing IP65 |
| Temperature drift on zero | 0.03%FS/℃(≤100KPa)0.02%FS/℃(＞100KPa) |
| Temperature drift on full scale | 0.03%FS/℃(≤100KPa)0.02%FS/℃(＞100KPa) |
| Operating Voltage | 12-36VDC |
Ⅲ. Application of Company Products
It is widely used for the temperature measurement in such industries as petroleum, chemical, metallurgy, environmental protection, food, water conservancy, urban water supply, oil fields and others.
Ⅳ. Product Details
Good stability, high precision, high performance/price ratio, directly put into the measured medium, easy to install and use, solid structure, no moving parts, high reliability, long service life, 4-20mA output.
Ⅴ. delivery, shipment and service of temperature sensors
The temperature sensor is packed in cartons. If you need, we can also make it for you.
Ⅵ. FAQ
1, are your manufacturer?
We are manufacturer, our factory localed in Shenzhen China.
2, what product you manufacturer have?
Our factory produce temperature sensor for power station,
Stators and cable for industry.
3, how many production lines do you have?
We have 10 production lines in Shenzhen factory.
4, how do you ensure product quality?
We already built a mechanical,electrical,fire and flame retardant laboratory, professional testing engineers.
5, can you send samples?
Yes, we will supply sample before your make the order.
Installation and wiring
